PERFORMANCE
Processor: Intel® Core i7-13650HX, 14C (6P + 8E) / 20T, P-core 2.6 / 4.9GHz, E-core 1.9 / 3.6GHz, 24MB
AI PC Category: AI-Powered Gaming PC
NPU: None
Graphics: NVIDIA® GeForce RTX™ 5050 8GB GDDR7, Boost Clock 2662MHz, TGP 115W, 440 AI TOPS
Chipset: Intel® HM770 Chipset
Memory: 1x 16GB SO-DIMM DDR5-4800
Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-4800 offering
Storage: 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots
Max Storage Support: Up to two drives, 2x M.2 SSD | M.2 2242 SSD up to 1TB each
Optical: None
Card Reader: None
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone: 2x, Array
Camera: HD 720p with E-shutter
Battery: 80Wh
Power Adapter: 245W Slim Tip (3-pin)
Special Features: AI Chip: LA1
DESIGN
Display: 15.3" WUXGA (1920x1200) IPS 300nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision®, G-SYNC®
Touchscreen: None
Screen-to-Body Ratio: IPS models: 90.9% AAR (active area ratio)
Color Calibration: Factory Color Calibration
Pen: Pen Not Supported
Keyboard: White Backlit, English
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH): 344.9 x 255.35 x 22.50-23.99 mm (13.58 x 10.05 x 0.89-0.94 inches)
Weight: Starting at 2.1 kg (4.63 lbs)
Case Color: Eclipse Black
Case Material: PC-ABS + 15% Talc (Top), PC-ABS + 15% Talc (Bottom)
Surface Treatment: Painting
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Home 2024 + Lenovo® AI Now
CONNECTIVITY
WLAN + Bluetooth: Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN: Non-WWAN
Ethernet: 100/1000M (RJ-45)
Standard Ports
-
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
-
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
-
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1
-
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
-
1x HDMI® 2.1, up to 8K/60Hz
-
1x Headphone / microphone combo jack (3.5mm)
-
1x Ethernet (RJ-45)
-
1x Power connector
Docking
Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 15IRX10
SECURITY & PRIVACY
Security Chip: Firmware TPM 2.0 Enabled
Fingerprint Reader: None
Other Security: E-shutter
SERVICE
Base Warranty: 1-year, Courier or Carry-in
Included Upgrade: 3Y Legion Ultimate Support -IPMAIN (ESS)
ACCESSORIES
Bundled Accessories: None
CERTIFICATIONS
Green Certifications
-
ErP Lot 6/26
-
RoHS compliant
Other Certifications
TÜV Rheinland® Low Blue Light (Hardware Solution)
MODEL INFORMATION
Model: 83LY00EWPH
